Oberheim TEO-5
The Oberheim TEO-5 Desktop Module is ideal for musicians, producers and synth enthusiasts looking to access iconic analogue tones in a more space-efficient form. With the same core engine as the TEO-5 keyboard version, it features five voices, each with two VCOs and a sub oscillator, offering a full, warm and expressive sound palette. The onboard SEM filter is capable of morphing from low-pass to high-pass, giving you fine-grained control over your tone.
Modulation is at the heart of the TEO-5. With a 19-slot matrix, dual five-wave LFOs and two five-stage envelopes, you can create highly dynamic patches with ease. The user-friendly layout means every parameter is accessible from the front panel, allowing for quick and intuitive sound sculpting. Built-in effects, a flexible arpeggiator, and a 64-step sequencer make it a complete creative tool in a compact format.
Compact desktop module with full Oberheim TEO-5 sound engine in a smaller form factor
Genuine analog signal path with two voltage-controlled oscillators and a sub oscillator per voice
Selectable triangle, saw, and variable pulse waves available simultaneously on each oscillator
Oscillator sync and through-zero FM via dedicated front-panel control
Switchable key tracking for each oscillator and integrated white noise generator
Authentic SEM filter with seamless morphing from low-pass to high-pass and selectable band-pass mode
Bi-polar filter envelope with velocity sensitivity and keyboard tracking
Two five-stage (DADSR) envelopes for filter and amplifier, each with velocity response and modulation routing
Two LFOs offering five waveforms, tempo sync, and flexible modulation assignments
Extensive modulation matrix with 19 sources and 64 destinations, supporting audio-rate modulation
Vintage knob adds analog-style voice variations for a classic sound
Channel aftertouch with bi-polar modulation routing options
Integrated master clock with tap tempo, BPM display, and MIDI clock synchronization
Versatile arpeggiator with multiple rhythms, octave ranges, and play modes
64-step polyphonic sequencer supporting ties and rests
Dedicated reverb with adjustable damping, pre-delay, decay, and tone
Multi-effects unit with delays, modulation effects, ring mod, phase shifter, distortion, and more
Independent overdrive circuit for added warmth and character
Performance features include note hold, polyphonic glide, unison mode, and manual live panel mode
512 total patch slots with 256 user and 256 factory programs organized in intuitive banks
Dual 1/4” audio outputs, headphone jack, MIDI in/out/thru, USB MIDI, volume pedal, and sustain input
Specifications
Oscillators:
Voices: 5-Voice VCO/VCF-Based Polysynth
Oscillators Per Voice: 2x VCOs And Sub Oscillator
Wave Shapes: Simultaneously Selectable Triangle, Saw, Variable Pulse
Oscillator Sync: Oscillator 1 Syncs To Oscillator 2
X-Mod: Dedicated Front-Panel Through-Zero FM Control
Key Tracking: Switchable Per Oscillator
Noise Generator: White Noise Accessible In Pre-Filter Mixer
State Variable Filter:
Type: Classic SEM Filter With Selectable Band-Pass Mode
State Knob: Morphs From Low-Pass Through Notch To High-Pass
Envelope Control: Bi-Polar Filter Envelope Amount
Velocity Modulation: Of Envelope Amount
Keyboard Tracking: Enabled
Filter Envelope:
Type: Five-Stage (DADSR) Envelope Generator
Velocity Modulation: Of Envelope Amount
Modulation Destinations: Freely Assignable
Amplifier Envelope:
Type: Five-Stage (DADSR) Envelope Generator
Velocity Modulation: Of Envelope Amount
2 Low Frequency Oscillators:
Wave Shapes: Triangle, Sawtooth, Reverse Sawtooth, Square, Random (Sample And Hold)
Tempo Sync: Enabled
Initial Amount: Setting Available
Modulation Destinations: Freely Assignable
Modulation Matrix:
Structure: 19 Slots x 19 Sources x 64 Destinations
Routing: Flexible Matrix With Audio Rate Capabilities
Vintage Knob:
Function: Adds Voice-To-Voice Variations In Component Behavior
Aftertouch:
Type: Channel (Mono) Aftertouch
Control: Bi-Polar Amount With Freely Assignable Destinations
Clock:
Master Clock: With Tap Tempo
BPM Control: With Display
MIDI Sync: MIDI Clock Sync Supported
Arpeggiator:
Note Values: 16th Note, 8th Note Triplet, 8th Note, Dotted 8th Note, Quarter Note
Octave Range: One, Two, Or Three
Modes: Up, Down, Up/Down, Random, Assign
Sequencer:
Type: Polyphonic Step Sequencer
Steps: Up To 64 With Ties And Rests
Effects:
Reverb: Damping, Pre-Delay, Decay, Tone
Multi-Effect: Stereo Delay, BBD Delay, Tape Delay, Chorus, Flanger, Oberheim Phase Shifter, Ring Modulator, Vintage Rotating Speaker, Distortion, High-Pass Filter, Lo-Fi
Overdrive: Dedicated Effect
Performance Controls:
Hold Switch: Latches Held Notes
Portamento: Polyphonic Glide
Unison Mode: Configurable Voice Count And Key Modes
Manual Switch: Front Panel Live Control
Patch Memory:
User Programs: 256
Factory Programs: 256
Banks: 32 Banks Of 16 Programs Each
Program Access: Direct And Single-Button Access
In/Out:
Audio Outputs: Left And Right (2 x 1/4” Jack)
Headphone Output: Stereo, 1/4” Phone Jack
MIDI: In, Out, And Thru Ports
USB: Bidirectional MIDI Communication
Pedal Inputs: Volume Expression And Sustain Footswitch
Dimensions: 59.4 x 24.6 x 19.1 cm
Weight: 4.5 kg
