Module: V51

Kick: KD-20-MS 20"

Snare: PD-14DSX 14" Digital

Tom 1: PDA-100-MS 10"

Tom 2: PDA-120-MS 12"

Floor Tom: PDA-140F-MS 14"

Hi-Hat: VH-14D 14" Digital

Ride: CY-18DR 18" Digital

Crash 1: CY-14R-T 14"

Crash 2: CY-16R-T 16"

Stands: DCS-30 (x2), DBS-30 (x1), PDS-5 (x1)

Specifications

Product Code: VAD516 KIT

Drum Kits: 200 (Preset: More Than 70)

Instruments: More Than 1,000

Power Supply: AC Adaptor

Current Draw: 1,700 mA

Power Consumption (Off Mode): 0.24 W

Number Of User Samples: Maximum 500 (Includes Factory Preloaded User Samples)

Total Sound Length: 24 Minutes In Mono, 12 Minutes In Stereo

Supported File Formats: WAV (44.1 kHz, 16/24 Bits)

Recording Method: Realtime

Maximum Note Storage: Approx. 40,000 Notes

Export File Formats: WAV (44.1 kHz, 16 Bits), SMF

Maximum Length: 60 Minutes (Temporary Recording: 1 Minute)

File Format: WAV (44.1 kHz, 16 Bits)

Connectors

Trigger Input Connector: DB-25 Type (Kick, Snare, Tom1, Tom2, Tom3, Hi-Hat, Crash1, Ride, Ride Bell, Hi-Hat Control)

Trigger In Jacks: 4 x 1/4-Inch TRS Phone Type (Crash 2, AUX 1/Tom 4, AUX 2, AUX 3)

Digital Trigger In Ports: 3 x USB A

Master Out Jacks: L/Mono, R - 1/4-Inch Phone Type, Unbalanced

Direct Out Jacks: 2 x 1/4-Inch TRS Phone Type, Unbalanced

Phones Jacks: Stereo 1/4-Inch Phone Type, Stereo Miniature Phone Type

Mix In Jack: Stereo 1/4-Inch Phone Type

MIDI Connectors: In, Out/Thru

USB Computer Port: USB Type-C (Class Compliant For Audio And MIDI / Roland Driver For Audio And MIDI)

Foot Switch Jack: 1/4-Inch TRS Phone Type

DC In Jack: Included

Effect Types

Layer Transient: Each Layer

Layer Equaliser: Each Layer

Pad Equaliser: Each Pad (By Head And Rim)

Pad Compressor: Each Pad (Head And Rim Common)

Overhead Mic Simulator: Included

Room/Reverb/Kit Resonance: Included

Bus Effect: 4 Systems (Two Can Be Used Simultaneously Per System, With Side Chain Function), 94 Types

Bus Reverb: Included

Master Compressor: Included

Master Equaliser: Included
