TECHNICAL SPECIFICATIONS

Transducer type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Dynamic

Operating principle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Open

Sound coupling to the ear . . . . . . . . . . . . . . . . . . Circumaural

Frequency response . . . . . . . . . . . . . . . . . . . . . . . . 5 - 40,000 Hz

Nominal impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Ω

Nominal sound pressure level

 @1 mW / 500 Hz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 dB SPL

Nominal sound pressure level

 @1 V / 500 Hz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114 dB SPL

Short term maximum input power . . . . . . . . . . . . . . . 100 mW

Rated maximum input power

 (continuous operation) . . . . . . . . . . . . . . . . . . . . . . . . . . 30 mW

THD @ 1 mW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.80% @ 100 Hz

0.05% @ 500 Hz

0.04% @ 1 kHz

Headband pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.3 N

Length and type of cable. . . 3 m (9.8 ft) / straight cable or

1.8 m (5.9 ft) / straight cable,

each detachable,

with 3-pin mini XLR cable connector,

single-sided

Connection . . . . . . . Gold-plated mini stereo jack (3.5 mm)

& 1/4" adapter (6.35 mm)

Weight (without cable) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 345 g
