Description

Studiologic presents Numa X Piano GT SE, a new model that expands the design, expressive control, and sound library of the Numa X Piano series. The metallic satin finish, handcrafted wooden side panels, extended memory, and new functions introduced by Firmware 3.0 make the GT SE the ideal partner for professional use on stage and in the studio.

Key features

•    Renewed aesthetics
•    Enhanced expressive control
•    Increased RAM
•    Firmware 3.0 with new features.
•    UX Logic interface

 Renewed aesthetics

Numa X Piano GT SE stands out with an elegant warm metallic gold color, giving the instrument a modern and distinctive presence on any stage. The solid wood sides add a touch of personality, in a design that combines refined engineering and artisanal attention to detail.

Enhanced expressive control

The Piano features the TP/400 Wood keyboard with a graded Hammer Action mechanism, escapement, and aftertouch, providing a solid and consistent touch that allows the musician complete expressive control, also thanks to the high-resolution dynamic control introduced with the new Firmware 3.0.

Increased RAM

The internal memory on the Numa X Piano GT SE has been doubled, reaching 4 GB. This allows for support of larger sound libraries, future expansions, and exclusive content.

UX Logic interface

Like the standard GT model, the Numa X Piano GT SE also implements Studiologic's UX Logic user interface, based on an essential layout comprising a series of color-coded encoders and a backlit OLED display that ensure logical and immediate control, ideal for any live and studio performance.

Firmware 3.0 new features

Studiologic debuts the new Firmware 3.0 on the Numa X Piano GT SE, which introduces significant improvements to the entire system's operation:

•    High-definition dynamic response:  High-definition dynamic response: the efficiency of the three contacts in the TP400W keyboard (*) for velocity detection is further optimized.
•    Significant increase in acoustic modeling: Enhanced Acoustic Modeling (Acoustic Piano)
•    New model for electric pianos (Electric Piano Modeling 2)
•    Synth section generator expanded with new expressive tools
•    Redesigned effects section with new FX such as: amplifier simulations, Chorale and Symphonic

   (*) TP/400 Wood with graded Hammer Action mechanism with escapement and aftertouch simulates the mechanism of a real concert piano and allows the musician complete expressive control.

Enhanced Acoustic Modeling Acoustic Piano


• Improved acoustic piano response thanks to a more efficient engine.

• More precise detection of touch variations.

• More accurate control of note release.

• New samples with increased timbre variety.

Electric Modeling 2 (Electric Piano)


• Updated engine for wider dynamics and more realistic behavior.

• Integrated amplifier simulations to modify the timbre as on original models.

• New “tine” presets (tine simulation).

• Simplified user interface for faster sound modification.

Brand new Synth Engine (Synthesizer)


• New sound engine for synths based on virtual oscillators.

• Produces classic waveforms and complex timbres.

• Dedicated controls for quick sound modification.

• Functions such as Portamento, Legato, Mono/Poly, and real-time controls.

Redesigned effects section

With the introduction of new FX such as: amplifier simulations, Chorale and Symphonic

Numa X Piano GT SE Technical Specifications

Keyboard


• 88 TP/400 WOOD keys with Graded Hammer Action mechanism

• Wooden keys

• Triple sensor detection system

• Escapement

• Aftertouch

• "Ivory feel" finish

Customization


• Dynamic curves: Soft, Medium, Hard, Fixed (programmable)

• Keyboard sensitivity control

• White/black key balance

Functions


• 250 User Programs

• Zoom function for quick Zone parameter editing

• 4 Zones assignable to internal sounds or external MIDI

• Split/Keyrange for each Zone

• Dedicated Split button

Favorites


• 16 Favorites banks with 24 Programs each

• Preview of Favorites content on the display

Global Equalizer


• Bass, Mid, Treble gain controls

• Mid frequency control

Sound Generation


• 8 Sound Banks with over 250 Factory sounds

• New sounds installable via Manager App

• Maximum polyphony: 300 voices

Acoustic Pianos


• Acoustic Modeling Technology

• Release samples, Damper and Key-off noises

• Zoom Controls: Tone, Strings Resonance, Duplex, Damper Noise

Electric Pianos


• Electric Modeling Technology: physical modeling of vintage and hybrid EPs

• Zoom Controls: Hammer, Offset, Tine, Damper Noise

Keyboards, Bass & Guitars, Organs, Synth, Orchestral, Other


• Zoom Controls: Filter Cutoff, Resonance, Attack, Release

Effects / Processing


• 8 independent Insert FX (2 per Zone)

FX1

Distortion, Overdrive, Auto Wah, Pedal Wah, Auto Pan, Tremolo, Vibrato, Equalizer, Compressor

FX2

Chorus 1, Chorus 2, Flanger 1, Flanger 2, Phaser 100, Phaser 90, Phaser HMX, Phaser Pad, Rotary, Auto Pan, Tremolo, Vibrato, Equalizer, Compressor

Master Delay

Delay, Pan Delay

Master Reverb

FDN (Feedback Delay Network) technology
Room 1, Room 2, Hall 1, Hall 2, Cath. 1, Cath. 2, Plate 1, Plate 2, Spring 1, Spring 2

Audio Inputs / Mixer


• 4 Mic/Line Audio Zones

• Configurations: 4 Mono, 1 Stereo + 2 Mono, 2 Stereo

• Zoom Controls: Gain / Low / Mid / Hi for each Audio Zone

Preset Delay FX (7)

Eko 1, Eko 2, Eko 3, Eko 4, Paneko 5, Paneko 6, Paneko 7

Preset Reverb FX (7)

Club, Lounge, Studio, Vocal, Stage, Bighall, Chorale

Controls / User Interface


• 2.8" color display (320 × 240)

• Master Volume

• Navigation encoder

• 13 encoders with push function

• Assignable encoder for input volume (Audio / USB / Audio+USB)

• 22 buttons

• 2 programmable sticks

  • Stick 1: bidirectional with spring return

  • Stick 2: directional without spring



Connections


• Audio OUT: 2× 6.3 mm TS jack (L+R)

• Audio IN: 4× 6.3 mm TS jack

• Headphones: 6.3 mm TRS jack

• Pedals: 2 auto switch/continuous, 1 universal

• MIDI: In/Out

• USB: Audio In/Out, MIDI In/Out, Manager App

Power Supply


• DC IN: 12V

Power Adapter


• Input: 100–240V

• Output: 12V – 2.5A

Dimensions and Weight


• Width: 128.0 cm / 50.4"

• Depth: 31 cm / 12.2"

• Height: 12.3 cm / 4.8"

• Weight: 22.0 kg / 48.5 lbs

Package Contents


• Numa X Piano GT

• SLP3-D triple pedal

• Power adapter

Compatible Accessories


• Softcase SIZE B, SIZE C

• Magnetic music rest TYPE B

• Magnetic computer platform TYPE B

Compatible Pedals

PS/100, PS/150, PS/250
VFP1/10, VFP1/15, VFP1/25
VFP2/10, VFP2/15
SLP3-D
VP/27
FP/50
