Dunlop GCB95 Cry Baby Standard Wah

Description

Dunlop GCB95 Cry Baby Standard Wah

The GCB95 Cry Baby® Standard Wah is a Jim Dunlop Wah pedal featuring the legendary Fasel® inductor, a precise high end, and an aggressive wah sound. OVERVIEW The Cry Baby Wah is one of the most iconic guitar effects in music history. When it first appeared on the scene in 1966, it added a new level of expression to the electric guitar. Musicians like Jimi Hendrix and Eric Clapton used the Cry Baby Wah to create timeless melodies in rock history. The GCB95 is a modern interpretation of those sounds, featuring the expressive character of the legendary red Fasel® inductor with a more precise high end and an even more aggressive wah sound. With a sturdy body and a Hot Potz Potentiometer tested for one million cycles, the Cry Baby Wah will withstand years of music. POWER This pedal can be powered by a 9-volt battery or, alternatively, with a 9-volt power supply like the Dunlop ECB003, or with external power supplies like the DC Brick™, Iso-Brick™, or Mini Iso-Brick™ (not included). KEY FEATURES

Specifications

• The legendary Cry Baby Wah sound;

• Simple and direct;

• Robust construction. GCB95 CRY BABY TECHNICAL SPECIFICATIONS Input Impedance: 800 kOhm Output Impedance: 10 kOhm Low-Pass Filter: 350 Hz - 450 Hz High-Pass Filter: 1.5 kHz - 2.5 kHz Nominal Input Level: -8.0 dBV Nominal Output Level: +10 dBV Maximum Gain Heel Down: +19.5 dB Maximum Gain Toe Down: +19 dB Signal-to-Noise Ratio Heel Down: 98 dBV Signal-to-Noise Ratio Toe Down: 89 dBV Current Draw: 0.9 mA
