Antelope Zen Q Synergy Core USB-C Audio Interface

Description

Antelope Zen Q Synergy Core USB-C Audio Interface

14x10 BUS POWERED USB-C AUDIO INTERFACE

Boost your desktop setup with high-end technology and take the next step in your creative pursuit. Zen Q Synergy Core allows you to thrive without limits by giving you access to renowned sound quality, real-time processing of analog modeled effects, and expandable I/O.

With Zen Q Synergy Core, you get sonically precise sound in your studio.

The interface has all the core performance quality that high-end Antelope Audio interfaces are known for, so you can reap the benefits of a seamless workflow for any desktop studio layout.

AD/DA converter chips guarantee 127dB of headroom with undeniable definition. The two ultra-linear preamps feature true console-grade circuitry, delivering warmth and capturing the natural details of any recorded instrument or voice. Zen Q comes with a virtual library of 37 free effects from the Synergy Core effects platform.

You will have access to everything you need to capture and process rich and dynamic sound.

The collection includes compressors, equalizers, and microphone preamps, as well as guitar cabinets and amplifiers to create your perfect guitar sound.

Zen Q Synergy Core can be easily integrated into any setup or workflow style you prefer. Its portability allows you to take the studio wherever you want to go, whether you are recording on location or performing a live set on stage. Record, mix, and stream with low latency, with no power supply needed.

Specifications

AD/DA conversion: 127dB of headroom

Sampling: 24-bit / 192kHz

64-bit AFC (Acoustically Focused Clocking) technology and jitter management algorithm for increased amplitude, separation and sound detail

2x Discrete ultra-linear preamps with 65dB gain for studio recordings

Microphone / Line / Hi-Z inputs, on combo XLR jack, provide 48V Phantom power

2x Hi-Z / Line instrument inputs on TRS

2x DC-coupled line outputs on TRS jacks

USB 2.0 Type-C port with 16 inputs and 16 outputs

Digitally expandable via ADAT IN, with 8 channels available

Digitally expandable via S/PDIF I/O, with 2 channels available

1x Stereo monitor output on TRS

2x Stereo headphone outputs with separate volume control

Power supply: Thunderbolt with no dedicated power source needed

Direct monitoring with Synergy Core effects, processed in real time with imperceptible latency

Simplified I/O routing with pre-configured settings, enabling immediate recording and playback

Customizable presets with signal routing, level adjustments, mixer, and effects settings

Customizable monitoring mixes with adjustable volume, pan, and reverb

Real-time effects processing

Collection of 37 Synergy Core effects modeled on classic and rare analog outboard gear

Proprietary integrated Synergy Core platform powered by 2x DSP and 1x FPGA chip for real-time effects processing

Modeling Engine for pairing with Edge microphones for real-time use of vintage microphone emulations

Dimensions: 198 x 137 x H57mm

Weight: 0.8kg
