Antelope Orion Studio Synergy Core Thunderbolt 3 / USB Interface

Description

Antelope Orion Studio Synergy Core Thunderbolt 3 / USB Interface

Antelope Audio Orion Studio Synergy Core is a state-of-the-art Thunderbolt 3 and USB interface with 12 discrete preamps and unparalleled DSP power.

Featuring Antelope's innovative Synergy Core FX and renowned FPGA, the Orion Studio Synergy Core is a first-class recording and mixing studio in a compact, rack-mountable solution.

Equipped with six ARM-based DSP processors and two proprietary FPGA (Field Programmable Gate Array) chips, the Orion Studio Synergy Core delivers incredible signal processing power.

Load up to 32 FX channel strips with 8 FX slots each for up to 256 FX instances. The Orion Studio Synergy Core comes bundled with a comprehensive collection of 50 real-time studio effects, meticulously modeled after classic analog hardware.

Instantly add a vintage vibe to your tracks with legendary studio compressors, EQs, mic presets, guitar amps, and more. And with the AFX2DAW plug-in, you can use Synergy Core effects as inserts within your favorite DAW.

Compatible with Thunderbolt 3, Thunderbolt 2, and USB 2, the Orion Studio Synergy Core offers ultra-fast connectivity with any DAW on Windows or Mac machines. Fill your channels with powerful effects without fear of session crashes.

And with Antelope's latency-free direct monitoring technology, you can create complex monitor mixes using four digital mixers with up to 32 assignable inputs.

Specifications

32 Channel Thunderbolt 3 & USB 2.0 Audio Interface

Includes 50 studio effects

Integrated FPGA for real-time calculation of effects

Antelope 64-bit acoustically focused clocking

12 Discrete mic preamps with up to 75 dB gain and +48 V phantom power

4 Hi-Z inputs

2 Stereo monitoring outputs with 130 dB dynamic range - can be operated in parallel or in A / B mode

2 Independent stereo headphone outputs

2 ReAmp outputs

16 Line outputs via DB25

Analogue inserts for inputs 1 & 2 (6.3mm TRS)

S / P-DIF input / output (2x RCA)

2 x ADAT input / output

DC-coupled inputs and outputs allow the transmission and reception of CV / Gate signals

Wordclock I / O

Extensive software control panel with flexible audio routing

Dimensions (W x D x H): 483 x 220 x 44 mm

Weight: 3.1 kg

System requirements: Windows 10 (64 bit), min. OS X 10.12 (10.14 Mojave recommended)
